Non Woven Fabrics Machinery
Nonwoven Cloth Roll Slitting Rewinding Machine
PPD-NWCS
Machine is mainly used for slitting and rewinding non woven jumbo roll into small roll with different size with or without perforation line.It is suitable for non-woven production lines and non-woven products factory.
This model is high speed and running smooth reliable operation etc,it suits for sunplace nonwoven,niddle punch non woven,PP nonwoven cloth etc.
Production Process:
Jumbo roll loading---Slitting into small size- Poeration option-Rewinding small width roll- Unload finished roll.
Main parameters:
Applicable materials: 25-350 - g / ㎡ non-woven fabrics
Raw material width:1300/1800/2500/2700/3500mm
Raw material size: Φ≤ 1200-1500mm
Paper core diameter of the raw material : Ø 76 mm
Paper core diameter of the product roll: Ø 76 mm option
Prodution speed: 120-300 m/min
Voltage: 220/380/415/450 v
Power: 3.5/7.5 kw
Weight: 3500-8500 kg
Non-woven Fabric Slitter Rewinder, Nonwoven Cloth Roll Slitting Rewinder, Nonwoven Slitting Rewinding Machine
