Aluminium Foil Rewinder
Semi Automatic Aluminium Foil &Cling Film Rewinder
PPD-AFCF350
Machine is designed for multi-functional rewinding of Aluminium foil,catering foil,kitchen foil,household foil roll,and PVC/PE cling film roll.It adopts the latest electronics/mechanicalsystems,it is for accurate length counter,tension control with touch color screen controled by PLC man-machine interface communication program.
Machine is for automatic starting rewinding,automatic stop when reach setting length,auto exchanging paper core shaft etc.
It built with complete of semi-automatic operation,it is very user friendly,th new non-skilled operator can run the machine.
Technical Data:
Material:Aluminium foil/Cling film
Material thickness:7-50 micro
Unwind roll width:350mm(Option)
Unwind roll max OD:900mm
Unwind paper core dia:76mm
Rewind sub roll length:5-900m
Rewind sub core dia:30/38/40mm（option）
Magnetic Tension control:50N.M
Speed for Aluminium Foil:Max 300m/minute
Speed for Cling Film :Max 650m/minute
Power:2.8kw
Voltage:380/145v option
