Four Side Sealing & Packaging Machine

Fully Automatic Eye Mask Slicing Packaging Machine

PPD-ASP80
Fully automatic eye mask slicing packaging machine is a machine suitable for the production of different eye masks. The machine automatically completes the entire process from slicing to packaging the finished product.
Machine is equipped with a color touch screen display interface, multiple languages are optional,which is easy to operate. It adopts a servo drive system and a PLC programmable controller to intelligently control the operation of the whole machine, ensuring the stable operation , precise slicing, and precise bag making.
This machine adopts a mobile synchronous heat sealing structure, the packaging sealing temperature is more uniform, the edge sealing effect is better, and it is suitable for packaging materials of different materials.
Production process:
Material feeding→ automatic slicing → automatic conveying → automatic liquid addition → automatic bag making and packaging → finished product

Main Data:
Model: PPD-ASP80
Eye mask specifications: 75x60mm (customizable)
Packaging bag specifications: 120x90mm(customizable)
Non-woven fabric roll specifications: Φ≤350mm, width ≤240mm, paper core inner diameter 76.2mm
Packaging film roll specifications: Φ≤350mm, width ≤580mm, paper core inner diameter 76.2mm
Packaging speed: 0-80 bags/min (2 pcs per bag)
Voltage: 220V, 50HZ
Power: motor 5KW, heating 5.6KW
Machine weight: 1300 kg
Machine dimensions: L3150mm ×W1600mm ×H1600mm



Fully automatic eye mask slicing packagi, Eye patch production line, Eye mask making machine
