Four Side Sealing & Packaging Machine
Pet Breath Oral Strip Making Machine
PPD- PBSM
Pet breath oral strip making machine can produce pet breath oral strip, breath clearing oral film, nicotine oral film and other thin films, suitable for pet care, daily chemical, health and other industries.This machine has uniform and efficient coating, and is equipped with an Acrylic Protective Cover to effectively prevent dust and other pollution. Independent temperature control system, precise temperature control, can adjust the temperature according to different raw material formulas to avoid over drying.
The machine operation is very simple, with PLC+touch screen and servo motor control. The machine has a high degree of automation. Just pour the mixed pet nutrition solution into the feeding port. After the machine starts, it will automatically evenly coating the solution on the isolation film. Then, it will be baked at high temperature to quickly solidify and form, and finally rolled up.
Main Data:
Model: PPD- PBSM
Coating width: Max 300mm
Coating thickness: 0.02-0.1mm
Coating speed: 0.01-1m/min (depending on different products)
Bottom film width: 360mm, Φ ≤ 350mm, ID:3inch
Voltage: 380v 50Hz
Power: Motor 1.5KW Heating 16KW
