Non Woven Fabrics Machinery
Non Woven Medical Dressing Folding Machine
PPD-NF100
Nonwoven medical dressing folding machine is used for folding and slitting of non-woven fabrics. The machine automatically folds and slits non-woven fabrics rolls into medical dressing.Machine is equipped with automatic counting device, frequency conversion speed regulation, unwinding synchronous traction, stable and simple operation , has a high production efficiency.
Process:
Non-woven fabric roll ---longitudinal folding---horizontal folding---cutting---finished product
Main Data:
Model: PPD-NF100
Applicable material: Spunlace non-woven fabric, 30-80gsm
Unfolding size: 100*100mm
Folded size: 50*50mm
Material width: 100mm
Inner diameter of mother roll: 76mm
Speed: 200-300pcs/min
Voltage: 220v/380v/415v, 50hz(option)
Power: 3.7kw
Different size can be customized.
